• Luggage rack, roof-mounted, Black (Please refer to (PDC) Cargo Package to order Luggage rack center rails.)
• Bumper, front, chrome
• Bumper, rear, chrome step, includes pad
• Air dam, Gray
• Moldings, bodyside, body-color, with bright insert
• Grille, chrome surround
• Assist steps, Black, mounted between front and rear wheels at bottom of rocker panel
• Headlamps, dual halogen composite, includes flash-to-pass feature and automatic lamp control
• Fog lamps, front, rectangular, halogen
• Mirrors, outside rearview, foldaway, power adjustable, heated, color-keyed (May be substituted with (DPN) Mirrors, outside rearview, power adjustable, heated, manual folding and extending on 3/4 ton Models.)
• Glass, Solar-Ray deep tinted (all windows except light tinted glass on windshield, driver and front passenger)
• Wipers, intermittent, front wet-arm with pulse washers
• Wiper, intermittent, rear, includes washer
• Body, liftgate with liftglass, rear door system, includes rear-window wiper/washer

• Seats, front leather appointed seating surfaces reclining buckets, includes adjustable head restraints, inboard armrests, 6-way power adjustable driver seat, floor console and rear storage pockets
• Seats, middle leather appointed 60/40 split-folding bench, 3-passenger with center armrest, storage tray and rear passenger easy entry (Upgradeable to (AL4) Seats, middle leather appointed Captains chairs.)
• Seats, rear 3rd row vinyl bench, 3-passenger, 1-piece removable
• Console, floor, includes storage area, cupholders and integrated 2nd row audio and HVAC controls
• Cupholders, in front seating area
• Cupholders, in rear of floor console
• Cupholders, driver and passenger side in 3rd row side trim
• Smokers Package, includes ashtray and lighter (Requires (A95) Seats, front reclining buckets or (AN3) Seats, front leather appointed seating surfaces power reclining full-feature buckets.)
• Floor covering, color-keyed carpeting
• Floormats, color-keyed, carpeted front and 2nd row, removable
• Steering wheel, leather-wrapped rim, Black
• Driver Information Center, full functionality included
• Tire pressure monitoring system (does not apply to spare tire)
• Tow/haul mode selector, button located at end of shift lever
• Warning tones, headlamp on, key-in-ignition, buckle-up reminder, turn signal on
• Windows, power, includes driver express-down and lockout features
• Door locks, power programmable, includes lockout protection
• Cruise control, electronic with set and resume speed, includes telltale in instrument panel cluster
• Keyless entry, remote, includes 2 transmitters, panic button and content theft alarm
• Air conditioning, tri-zone, automatic, individual climate settings for driver, right front passenger and rear passengers, includes front and rear HVAC systems
• Heater and defogger, includes front and side window defoggers, rear passenger heating ducts and heater, rear auxiliary
• Defogger, rear-window, electric
• Sound system, ETR AM/FM stereo with CD player, includes seek-and-scan, digital clock, auto-tone control, speed-compensated volume and Radio Data System (RDS) (Upgradeable to (UC6) Sound system, ETR AM/FM stereo with in-dash 6-disc CD changer.)
• Sound system feature, Bose Premium speaker system, 9 speakers, includes subwoofer in center console
• Sound system feature, rear audio controls, includes dual headphone jacks (headphones not included), power outlet and controls for volume, station selection and media
• OnStar, one-year of Safe and Sound service. Includes Automatic Notification of Air Bag Deployment, Emergency Services, Stolen Vehicle Location Assistance, Remote Door Unlock, OnStar Vehicle Diagnostics, Roadside Assistance, Accident Assist and Remote Horn and Lights. Also featuring Hands-Free Calling (OnStar services require vehicle electrical system (including battery), wireless service and GPS satellite signals to be available and operating for features to function properly. OnStar acts as a link to existing emergency service providers. OnStar Vehicle Diagnostics available on most 2004 MY and newer GM vehicles. Diagnostic capability varies by model. Visit onstar.com for system limitations and details. Not available with FDR order types. Not available with a ship-to of Puerto Rico or the Virgin Islands. If the order type is FDR, (UE0) OnStar, delete will be be forced on.)
• Power outlets, auxiliary, 2 on instrument panel, 1 in cargo area, 12-volt
• Door trim, lights on front doors, side reflectors on rear doors
• Armrests, driver and passenger doors, padded
• Mirror, inside rearview, electrochromic (light-sensitive auto-dimming), 8-point compass, outside temperature indicator and right front passenger air bag status
• Console, overhead mini, includes map lights and rear seat HVAC controls (Includes sunroof controls when (CF5) Sunroof, power is ordered.)
• Visors, padded, Shale-colored, driver and passenger side with cloth trim, extends on rod, illuminated vanity mirrors and corner storage pockets on back of visors
• Assist handles, front passenger and outboard 2nd row seats
• Coat hooks, driver and passenger side, rear seat and cargo area
• Lighting, dome lamp, driver and passenger side door switch with delayed entry feature, cargo lamps, door handle or keyless remote activated illuminated entry, map lights in front and 2nd seat positions
• Storage bin, behind rear driver side quarter panel

• Brakes, 4-wheel antilock, 4-wheel disc, hydroboost
• Air bags, frontal, dual-stage, driver and right front passenger, includes Passenger Sensing System (Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owners Manual for more safety information.)
• StabiliTrak, stability control, includes Proactive Roll Avoidance

ENGINE, VORTEC 5300 V8 SFI FLEX-FUEL, CAPABLE OF RUNNING ON UNLEADED OR UP TO 85% ETHANOL

• (295 HP [219.7 kW] @ 5200 rpm
• 335 lb.-ft. [452.3 N-m] @ 4000 rpm) (STD)

• Vehicle
• Rear Door Type: Liftgate
• Mileage
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 19
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 160
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): 16.8
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3150
• Gross Axle Wt Rating - Rear (lbs): 4000
• Curb Weight - Front (lbs): 2666
• Curb Weight - Rear (lbs): 2443
• Gross Vehicle Weight Rating Cap (lbs): 7000
• Gross Combined Wt Rating (lbs): 13000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 600
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 7500
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1000
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): N/A
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): N/A
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 5-Link Coil
• Spring Capacity - Front (lbs): 3150
• Spring Capacity - Rear (lbs): 4000
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3400
• Axle Capacity - Rear (lbs): 4000
• Axle Ratio (:1) - Rear: 3.42
• Shock Absorber Diameter - Front (mm): 46
• Shock Absorber Diameter - Rear (mm): 46
• Stabilizer Bar Diameter - Front (in): 1.25
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.0 x 1.1
• Rear Brake Rotor Diam x Thickness (in): 12.9 x 1.2
• Tires
• Front Tire Order Code: QMJ
• Rear Tire Order Code: QMJ
• Spare Tire Order Code: QMJ
• Front Tire Size: P265/70R16
• Rear Tire Size: P265/70R16
• Spare Tire Size: P265/70R16
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 7.0
• Rear Wheel Size (in): 16 x 7.0
• Spare Wheel Size (in): - TBD -
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Recirculating Ball
• Steering Ratio (:1), On Center: 15.8
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 43.0
• Turning Diameter - Wall to Wall (ft): 46.0
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 31
• Fuel Tank Location: Inboard LH Frame Rail
• Exterior Dimensions
• Wheelbase (in): 130.0
• Length, Overall w/rear bumper (in): 219.3
• Width, Max w/o mirrors (in): 78.8
• Height, Overall (in): 75.8
• Overhang, Front (in): 36.9
• Overhang, Rear w/bumper (in): 52.3
• Ground to Top of Load Floor (in): 31.3
• Ground Clearance, Front (in): 9.8
• Ground Clearance, Rear (in): 8.4
• Rear Door Opening Height (in): - TBD -
• Rear Door Opening Width (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Console (in): - TBD -
• Cargo Area Length @ Floor to Seat 1 (in): 104.6
• Cargo Area Length @ Floor to Seat 2 (in): 69.6
• Cargo Area Length @ Floor to Seat 3 (in): 36.1
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 49.1
• Cargo Box (Area) Height (in): 40.5
• Cargo Volume to Seat 1 (ft³): 131.6
• Cargo Volume to Seat 2 (ft³): 90.0
• Cargo Volume to Seat 3 (ft³): 45.7
• Interior Dimensions
• Passenger Capacity: 8
• Front Head Room (in): 40.7
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 61.4
• Second Head Room (in): 39.0
• Second Leg Room (in): 39.1
• Second Shoulder Room (in): 65.1
• Second Hip Room (in): 61.3
• Third Head Room (in): 38.6
• Third Leg Room (in): 36.1
• Third Shoulder Room (in): 64.8
• Third Hip Room (in): 49.2
• Summary
• Vehicle Name: GMC Yukon XL
• Body Style: 4 Door 1500
• Body Code: E52
